NeonInk

NeonInk is Aptlantis Studio's whole-brand visual and semantic design standard. It governs website UI, generated SVG artifacts, SESM metadata, Tailwind/CSS tokens, Canva assets, presentations, social graphics, and future marketing surfaces for the Aptlantis ecosystem.

:::info Document Lineage NeonInk's Docs/ folder contains several versions of the same ideas written at different times. This overview is built from NeonInk-v0.1.1.md, the most current and complete draft (it adds the App Development Addendum in §16.6 and the four-layer SESM/NIPC/AIC/Neon Ink model). NeonInk-v0.1.md is the earlier v0.1 draft and is superseded by v0.1.1. NeonInk-TagTheme.md is a pre-NIPC source note whose ideas are now canonicalized in NIPC. There is no README.md in this standard's source folder, so v0.1.1 doubles as both the framing document and the spec body. :::

Neon Ink System Mindmap

Status: Draft v0.1.1 Host System: Aptlantis Studio Scope: Whole-brand visual and semantic design standard for website UI, generated SVG artifacts, SESM metadata, Tailwind/CSS tokens, Canva assets, presentations, social graphics, and future marketing surfaces.

1. Overview

Neon Ink is the governing design standard for Aptlantis Studio.

Neon Ink Design System
├── Design Pillars
├── Semantic Color Taxonomy
├── Background Hierarchy
├── Interface Grammar
├── Technical Integration
└── Typography

It defines how the Studio should look, read, behave, and describe itself across:

static website pages
generated HTML
compiled SVG panels
SESM metadata blocks
dataset and pipeline cards
theme boards
documentation pages
Canva brand assets
slide decks
social and promotional graphics
future brand surfaces

Neon Ink is not only a color palette. It is an artifact-driven interface standard.

Its core rule is:

Visuals are derived from the data.

The website, SVGs, cards, theme boards, and marketing surfaces should feel like parts of the same durable archive: static enough to last, structured enough to regenerate, and expressive enough to make datasets worth exploring.

2. Source Map

This v0.1.1 specification synthesizes the current Aptlantis Studio materials into one canonical standard.

Reference categories used:

SESM precedent: the SVG Embedded Semantic Metadata standard (SESM-v0.2-Aptlantis-Studio.md in this standard's Docs/ folder is a working copy kept for the spec chain — see SESM Relationship)
Palette contract: NIPC — Neon Ink Palette Contract
Brand guidelines: aptlantis_studio_brand_guidelines.pdf (see References)
Neon Ink system docs: design manual, roadmap, taxonomy expansion, and tag theme notes
Implementation notes: CSS/Tailwind token docs and component pattern examples
Raw artifact examples: SVG panel XML with embedded SESM metadata (see SVG Panel Examples)
Visual references: web mockups, theme panels, infographics, logo panels, and latest HTML screenshots (see the asset galleries in the sidebar)

When these sources conflict, this spec resolves the conflict by best synthesis. It chooses the rule that is clearest, most reusable, most compatible with SESM, and most useful for building final Aptlantis Studio pages.

3. Status & Scope

3.1 Status

This is the current canonical Neon Ink document.

From v0.1 forward, new final pages and brand assets should follow this spec unless a named theme variant explicitly overrides part of it.

3.2 In Scope

Neon Ink governs:

color roles and semantic tokens
typography roles
panel and component grammar
page composition
desktop application surfaces
stateful tool panels
data-dense archive and catalog views
dataset and pipeline visualization
SESM theme requirements
brand voice and content language
brand collateral such as Canva templates, social posts, and presentations

3.3 Out of Scope

Neon Ink does not:

replace SESM
define a full dataset schema
define Rust generator internals
define access control, crawler policy, or licensing policy
require one frontend framework
require all artifacts to be SVG
require marketing graphics to expose private build metadata

Neon Ink provides whole-brand expression and page/component grammar. NIPC provides canonical palette semantics. SESM provides embedded metadata conventions.

4. Design Philosophy

4.1 Signal Over Scale

Aptlantis Studio exists for high-signal datasets, focused pipelines, and small specialist models. Neon Ink should make that philosophy visible.

The interface must prioritize recognition, status, provenance, and reproducibility over decorative novelty.

4.2 Local-First Durability

Studio artifacts should remain meaningful when copied, mirrored, archived, screenshotted, or viewed outside the original website.

Generated SVGs should carry semantic context through SESM. Static pages should expose visible metadata where trust matters.

4.3 Panels As Artifacts

The default component model is not a generic dashboard card.

It is an artifact panel:

Element	Meaning
Panel	Artifact container
Border/accent	Artifact type or classification
Glow	State or activity
Badge	Short state, role, or dataset class
Metadata	Trust, provenance, and scanability
Link/action	Canonical destination or next operation

4.4 Dataset-First Publishing

Aptlantis Studio is a dataset and pipeline workshop before it is a model showcase.

Pages should answer:

What is this dataset?
What is it for?
What produced it?
What state is it in?
What does it contain?
What licenses or constraints matter?
How can it be downloaded, inspected, reproduced, or extended?

4.5 Welcoming Technicality

Neon Ink should feel technical without becoming hostile or obscure.

The voice is precise, inventive, durable, and builder-friendly. It should avoid corporate AI hype and vague claims.

4.6 Desktop Application Adaptation

Neon Ink may be used for durable desktop tools, not only web pages and generated SVGs. In application contexts, clarity and repeat use take priority over poster-like intensity.

Desktop implementations should:

use panels as working surfaces, not decorative cards;
keep dense lists quiet, with neon reserved for state, type, selection, and risk;
expose active process state through borders, icons, and restrained glow;
preserve readable contrast on dark backgrounds without relying on glow alone;
use semantic icons for file type, operation type, health state, and verification state;
keep destructive, warning, and verification states visually distinct at a glance.

Neon Ink desktop apps should feel like operating consoles for retained context: structured, durable, and alive enough to show what needs attention.

5. Terminology

Artifact

A generated or curated unit with semantic meaning. Examples: dataset card, pipeline panel, SVG header, theme board, download card, release summary, or social asset.

Artifact Panel

A visual container that presents one artifact and exposes its type, state, metadata, and destination.

Semantic Role

A named meaning mapped to an NIPC color token, such as info, pipeline, memory-anchor, verified, constraint, or code-heat.

Glow

A state amplifier used sparingly around active, verified, caution, critical, or focused surfaces. Glow is not a background decoration. It should reinforce semantic meaning already carried by color, border, label, or icon.

Semantic Family

An NIPC color family that groups related roles by cognitive purpose, such as clarity/orientation, trust/validation, attention, risk, process, build/code, discovery, research, or neutral/archive.

Psychological Intent

The reason a semantic role was chosen, written for future generators, validators, and agents. Examples: orient-the-user, explain-system-flow, create-confidence, or mark-risk-before-proceeding.

State

The current activity or reliability condition of an artifact, such as idle, active, running, featured, complete, verified, warning, error, archived, or experimental.

Theme Variant

A named visual subtheme that inherits Neon Ink rules while adjusting accent emphasis for a subject area. Example: Dungeon Synth.

SESM Block

A JSON object embedded in an SVG <metadata> element according to SESM v0.2.0. See the SESM standard.

Brand Surface

Any public-facing material that presents Aptlantis Studio, including the website, Canva graphics, presentations, social posts, screenshots, and exported images.

6. Brand Foundation

6.1 Position

Aptlantis Studio creates and publishes unique, niche, practical, and creative datasets for fine-tuning small local models.

It is not a massive scrape marketplace. It is a focused workshop for reproducible, human-sized model building.

6.2 Audience

Primary audiences:

hobbyist model builders
local AI experimenters
dataset curators
archivists and researchers
creative tool makers
developers building small specialist models

6.3 Personality

Neon Ink should feel:

Inventive: experimental and future-facing
Durable: archive-aware, reproducible, and local-first
Welcoming: builder-friendly, not corporate
Precise: clear about data, schemas, licenses, and build state
Expressive: manga/cyberpunk energy without sacrificing scanability

6.4 Core Phrases

Preferred campaign language:

Unique datasets.
Real worlds.
Local power.
Build small. Train local. Create worlds.
High-signal datasets for small specialist models.
Compiled artifacts for reproducible local training.

7. Color & Token System

7.1 Background Layers

The background system creates depth through value shifts, not heavy chrome.

Token	Hex	Role
`--studio-void`	`#050816`	Deep baseline canvas
`--studio-base`	`#0B0F1A`	Page baseline and primary surface
`--studio-panel`	`#111827`	Artifact container
`--studio-raised`	`#162033`	Raised or emphasized panel layer
`--studio-soft`	`#0F172A`	Soft secondary panel layer

Use the Void as the outermost environment. Use Base for main page regions. Use Panel for artifact containers.

7.2 Text Tokens

Token	Hex	Role
`--studio-text`	`#E5E7EB`	Primary text
`--studio-text-secondary`	`#CBD5E1`	Secondary text
`--studio-muted`	`#94A3B8`	Metadata and supporting text
`--studio-faint`	`#64748B`	Quiet timestamps, IDs, and low-priority labels
`--studio-inverse`	`#050816`	Text on bright neon fills

7.3 NIPC Authority

NIPC is the canonical palette layer for Neon Ink. This document may summarize palette behavior, but final token names, color families, psychological intent, intensity rules, and palette validation come from NIPC — Neon Ink Palette Contract.

Use this four-layer model:

Layer	Canonical Document	Responsibility
Meaning	SESM standard	Embedded metadata, identity, provenance, links, agent hints
Palette	NIPC	Hue, semantic family, psychological intent, intensity validation
Contract	AIC	Artifact type, required fields, layout, render targets
Expression	This document (Neon Ink)	Brand system, typography, panel grammar, page composition
Geometry	APGC	Shape families, angle energy, corner profiles, safe zones, manga composition

Core rule:

Color should reduce cognitive load before it adds beauty.

7.4 Core Stable Tokens

The original Neon Ink tags remain the stable base. NIPC expands them into families rather than replacing them.

Core Token	Hex	NIPC Family	Primary Use
`info`	`#22D3EE`	Clarity / Orientation	General info, calm understanding
`process`	`#A78BFA`	Process / Transformation	Pipelines, how-it-works, system flow
`featured`	`#F472B6`	Discovery / Creative	Featured, creative, spotlight content
`success`	`#34D399`	Trust / Validation	Validated, good, evidence-backed pass
`important`	`#FACC15`	Attention / Learning Anchor	Caveats, notes, memory anchors
`critical`	`#F43F5E`	Risk / Constraint	Risk, blocker, failure, urgency
`code-heat`	`#F97316`	Creation / Build / Code	Rust, build, execution, artifact output
`experimental`	`#818CF8`	Research / Experimental	Prototype, research, unsettled work
`canonical`	`#E5E7EB`	Canonical / Archive / Neutral	Definitions, schemas, anchor text

7.5 Dataset Accent Language

Dataset accents describe subject matter, not global state.

Dataset Accent	Primary Token	Use
Rust / Code Heat	`code-heat`	Rust corpora, compiler material, crate metadata, build pipelines
RPG / Dungeon Synth	`process`, `creative`, or named variant	Tabletop, lore, NPC dialogue, items, spells, worlds
Creative / Discovery	`featured`, `creative`, `discovery`	Generative writing, worldbuilding, featured creative releases
Verified / Complete	`success`, `verified`, `reproducible`	Release-ready artifacts, license pass, quality pass
Review / Warning	`important`, `caution`, `decision`	Partial validation, caveats, manual review
Error / Failed	`critical`, `error`, `blocked`, `constraint`	Broken builds, failed validation, blockers

7.6 Legacy Color Aliases

Older mockups and raw SVG artifacts may use earlier neon values.

Known legacy aliases:

Legacy Value	Canonical Role	Canonical Value	Allowed Use
`#00E5FF`	`structure`	`#22D3EE`	Existing generated SVGs and preserved mockups
`#00AFC7`	`structure` border	`#22D3EE`	Existing SVG strokes
`#B554FF`	`process` variant	`#A78BFA`	Existing SVG violet accents
`#FF7A18`	`code-heat` variant	`#F97316`	Existing Rust SVG accents
`#50E060`	`success` variant	`#34D399`	Existing SVG status labels
`#FF2E96`	`discovery/error variant`	`#F472B6` or `#F43F5E`	Existing mockup emphasis only

New final pages should use NIPC v0.1 tokens unless preserving an existing generated SVG or creating a named theme variant. See SVG Panel Examples for real generated panels that still use these legacy values.

7.7 NIPC-Compatible Theme Token JSON

{
  "name": "Aptlantis Studio - Neon Ink",
  "version": "0.1.0",
  "mode": "dark",
  "colors": {
    "background": {
      "void": "#050816",
      "base": "#0B0F1A",
      "panel": "#111827",
      "raised": "#162033",
      "soft": "#0F172A"
    },
    "text": {
      "primary": "#E5E7EB",
      "secondary": "#CBD5E1",
      "muted": "#94A3B8",
      "faint": "#64748B",
      "inverse": "#050816"
    },
    "semantic": {
      "info": "#22D3EE",
      "structure": "#06B6D4",
      "navigation": "#38BDF8",
      "reference": "#7DD3FC",
      "orientation": "#67E8F9",
      "success": "#34D399",
      "verified": "#22C55E",
      "stable": "#86EFAC",
      "reproducible": "#2DD4BF",
      "available": "#A7F3D0",
      "important": "#FACC15",
      "note": "#FDE047",
      "caution": "#FBBF24",
      "decision": "#F59E0B",
      "memory_anchor": "#FEF08A",
      "critical": "#F43F5E",
      "error": "#EF4444",
      "blocked": "#FB7185",
      "constraint": "#E11D48",
      "deprecated": "#BE123C",
      "process": "#A78BFA",
      "pipeline": "#C084FC",
      "transform": "#D8B4FE",
      "automation": "#8B5CF6",
      "code_heat": "#F97316",
      "build": "#FB923C",
      "operation": "#FDBA74",
      "artifact_output": "#EA580C",
      "featured": "#F472B6",
      "creative": "#EC4899",
      "discovery": "#E879F9",
      "spotlight": "#F0ABFC",
      "experimental": "#818CF8",
      "research": "#6366F1",
      "prototype": "#A5B4FC",
      "canonical": "#E5E7EB",
      "archive": "#94A3B8",
      "muted": "#64748B",
      "unknown": "#CBD5E1"
    }
  }
}

7.8 Tailwind Token Map

export default {
  theme: {
    extend: {
      colors: {
        studio: {
          void: "#050816",
          base: "#0B0F1A",
          panel: "#111827",
          raised: "#162033",
          soft: "#0F172A",
          text: "#E5E7EB",
          secondary: "#CBD5E1",
          muted: "#94A3B8",
          faint: "#64748B",
          cyan: "#22D3EE",
          structure: "#06B6D4",
          navigation: "#38BDF8",
          violet: "#A78BFA",
          magenta: "#F472B6",
          green: "#34D399",
          yellow: "#FACC15",
          red: "#F43F5E",
          orange: "#F97316",
          advanced: "#3B8DFB",
          experimental: "#818CF8",
          archive: "#94A3B8",
          critical: "#F43F5E",
          caution: "#FBBF24",
          verified: "#22C55E",
          reproducible: "#2DD4BF",
          build: "#FB923C",
          creative: "#EC4899"
        }
      },
      boxShadow: {
        "glow-idle": "0 0 0 rgba(34, 211, 238, 0)",
        "glow-soft": "0 0 16px rgba(34, 211, 238, 0.28)",
        "glow-active": "0 0 24px rgba(34, 211, 238, 0.45)",
        "glow-violet": "0 0 24px rgba(167, 139, 250, 0.42)",
        "glow-magenta": "0 0 24px rgba(244, 114, 182, 0.42)",
        "glow-success": "0 0 24px rgba(52, 211, 153, 0.42)",
        "glow-warning": "0 0 24px rgba(250, 204, 21, 0.38)",
        "glow-danger": "0 0 24px rgba(244, 63, 94, 0.45)",
        "panel": "0 8px 30px rgba(0, 0, 0, 0.35)"
      },
      fontFamily: {
        mono: ["JetBrains Mono", "Cascadia Code", "monospace"],
        display: ["Rajdhani", "Orbitron", "system-ui", "sans-serif"]
      }
    }
  }
};

See CSS & Tailwind Tokens for the earlier pre-NIPC token snapshot and Component Patterns for HTML usage examples.

8. Typography

8.1 Display Typography

Display type carries the brand's energy.

Use for:

hero headlines
campaign phrases
large theme labels
high-energy section headers

Preferred character:

bold or heavy
condensed when available
optionally italic for campaign surfaces
uppercase where it improves scanability

Do not use display styling for dense metadata or long explanatory paragraphs.

8.2 System Mono

Monospace type is the technical backbone.

Use for:

dataset IDs
version numbers
pipeline names
build status
commands
labels
metadata rows
manifest references
compact navigation labels

Recommended stack:

font-family: "JetBrains Mono", "Cascadia Code", monospace;

8.3 Body Copy

Body copy should be plain, readable, and direct.

Let panels, semantic color, and SVG artifacts carry the visual intensity. Body copy should provide clarity, not decoration.

8.4 Hierarchy

Recommended hierarchy:

Role	Style
Hero headline	Display, heavy, large
Section heading	Display or mono, compact uppercase
Artifact title	Strong sans or display, readable
Metadata label	Mono, uppercase, muted
Metadata value	Mono or strong sans, semantic color when needed
Body	Plain sans or readable mono, restrained

9. Layout & Page Composition

9.1 General Page Rules

Pages should feel like navigable archives, not generic SaaS dashboards.

Use:

dark layered backgrounds
clear left or top navigation
dense but organized metadata
artifact panels with visible roles and states
semantic color used for meaning, not random decoration
enough negative space to avoid visual noise

Avoid:

generic blue SaaS gradients
decorative cards with no semantic role
hiding provenance or status
overusing glow on static content
making every page a marketing hero
burying dataset identity below generic navigation

9.2 Home Page

The home page introduces the Studio and immediately exposes useful dataset activity.

Required content patterns:

brand identity or wordmark visible in the first viewport
concise Studio proposition
primary dataset or featured artifact
quick stats
recent datasets
latest pipeline runs
route to datasets and pipelines
visible active theme or system identity

The home page may use a large visual hero, but it should still behave like a working archive entry point.

9.3 Dataset Detail Page

Dataset pages are the most important artifact pages.

Required content patterns:

dataset identity header
semantic tags
state badge
quality or validation signal when available
core stats: records, tokens, size, license, created/updated dates
download or canonical action
samples, structure, pipelines, versions, and changelog navigation
overview and composition summary
latest pipeline run
compatibility and related datasets
visible provenance or metadata when trust matters

Dataset pages should support quick scanning before reading long explanations.

9.4 About & Documentation Pages

About and docs pages should explain the system without losing the artifact grammar.

Use:

Q&A accordions or structured sections
semantic dot/bar indicators
compact examples
visible definitions
links to canonical specs, manifests, and datasets

Avoid turning documentation into a plain article page when componentized artifact panels would clarify the system.

9.5 Pipeline Pages

Pipeline pages must make process state visible.

Required content patterns:

pipeline name and version
associated dataset
current state
stages such as collect, filter, normalize, dedupe, structure, shard, validate
completion timestamps
record/token changes
warnings and errors
link to logs, reports, or manifests when available

Use violet for process and running states. Use green, yellow, and red for validation outcomes.

9.6 Theme Boards

Theme boards demonstrate semantic mapping, not only mood.

Required content patterns:

theme name and ID
background layers
semantic role swatches
state behavior examples
component examples
intended use
SESM theme summary when used for generated SVGs

9.7 Marketing Surfaces

Marketing assets should preserve the Studio's artifact language.

Use:

dark backgrounds by default
cyan, violet, and magenta as the primary brand triad
monospace labels and status language
short technical copy
dataset/pipeline artifacts as visual anchors
wordmark with generous spacing

Marketing surfaces may be more expressive than the website, but they should not contradict the semantic color roles.

10. Component Grammar

10.1 Panel State Table

State	Visual Behavior	Semantic Meaning
`idle`	Dim border, no glow	Dormant, quiet, or default artifact
`active`	Soft cyan glow	Current, selected, browsed, ready
`running`	Pulsing violet glow	Pipeline or transformation in progress
`featured`	Magenta glow	Notable, new, creative, highlighted
`complete`	Green emitter	Completed successfully
`verified`	Green status signal	Quality or license verified
`warning`	Yellow accent/glow	Needs review or has caveat
`error`	Red accent/glow	Failed, blocked, invalid
`archived`	Slate/gray muted styling	Dormant, mirrored, historical
`experimental`	Indigo or magenta-violet accent	Non-canonical or in progress

Use NIPC for hue and AIC for state strength. A panel has one dominant semantic accent; secondary colors should appear only as small badges, icons, rails, or metadata dots.

10.2 Artifact Panel Requirements

An artifact panel should expose:

title
artifact type or category
state badge when state matters
semantic accent
brief description
key metadata
canonical action or destination

Dataset and pipeline panels should expose enough metadata for trust, not only visual appeal.

10.3 Badges

Badges should be:

short
uppercase
state-driven or role-driven
colored by semantic meaning
readable at small sizes

Examples: ACTIVE, RUNNING, VERIFIED, WARNING, FAILED, RUST, CODE, TRAINING, RPG.

10.4 Tags

Tags identify subject matter or semantic category.

Tags should use color consistently:

Rust and compilation tags use orange.
Process and pipeline tags use violet.
Navigation/info tags use cyan.
Featured or creative tags use magenta.
Warning tags use yellow.
Error tags use red.

10.5 Q&A Accordion Pattern

Q&A entries should support peripheral recognition.

Recommended sequence:

Number -> Colored indicator -> Title text -> Expand/collapse icon

Use the colored indicator to communicate context before the user reads the full question.

Examples:

Orange dot: Rust or code-heavy question
Cyan dot: structure or general information
Violet dot: pipeline or implementation process
Yellow dot: caveat or review note

10.6 Links and Actions

Color links by purpose:

Link Purpose	Color
Navigation/indexing	Cyan
Process/action	Violet
Discovery/featured	Magenta
Download/release-ready	Green or cyan
Dangerous/destructive	Red

See Component Patterns for full HTML examples of these rules.

11. Dataset, Pipeline, and Artifact Patterns

11.1 Dataset Card Metadata

Dataset cards should include the strongest available subset of:

{
  "dataset": {
    "id": "rust-code-corpus",
    "title": "Rust Code Corpus",
    "state": "active",
    "domain": "rust",
    "tags": ["rust", "code", "training"],
    "records": 532104,
    "tokens": "18.7B",
    "size": "7.2 GB",
    "license": "MIT",
    "quality_score": 96,
    "created": "2025-04-12",
    "updated": "2025-05-18",
    "models_supported": ["Local", "GGUF"]
  }
}

The exact data source may be JSON, JSONL, TOML, YAML, or another manifest, but the visible card should preserve the same trust signals.

11.2 Pipeline Run Card

Pipeline run cards should include:

pipeline ID
associated dataset
state
stage list
progress or completion signal
records changed
tokens changed when available
error and warning counts
completed or updated timestamp
link to report, log, or canonical pipeline page

Recommended stage language:

Collect -> Filter -> Normalize -> Dedupe -> Structure -> Shard -> Validate

11.3 Stats Tiles

Stats tiles should be compact and scannable.

Use mono labels, semantic values, restrained borders, and no decorative glow unless the stat communicates live state.

Common stats: total datasets, total records, total tokens, pipelines, models supported, last update, unique crates, license pass, duplicate rate, average tokens per record.

Related dataset lists should preserve category color and visible type tags. They should help users move laterally through the archive without losing context.

11.5 SVG Artifact Panels

SVG artifact panels are first-class content when they carry SESM metadata.

They should:

remain valid SVG
include <metadata id="sesm"> when generated or semantically meaningful
preserve aspect ratio
expose readable text where possible
avoid relying only on visual inference for meaning
link or point back to canonical HTML when possible

See SVG Panel Examples for real compiled panels.

12. SVG + SESM Requirements

12.1 Relationship To SESM

Neon Ink uses SESM v0.2.0 (see the SESM standard) as its embedded semantic metadata carrier for SVG artifacts.

SESM remains the metadata standard. NIPC defines palette semantics. Neon Ink defines the brand expression and visual grammar that SESM can reference.

The Artifact Interface Contract (AIC) v0.1 defines the bridge across the systems. Where SESM says what an artifact is, NIPC says what its color semantics mean, and Neon Ink says how the brand behaves, AIC says exactly how that artifact renders across SVG, HTML, metadata, and interaction targets.

DATA -> SESM -> AIC -> SVG/HTML -> USER

Generated Aptlantis Studio artifacts should treat these documents as a four-layer system:

Layer	Canonical Document	Responsibility
Meaning	SESM standard	Metadata, identity, provenance, links, agent hints
Palette	NIPC	Color families, semantic roles, psychological intent, intensity validation
Contract	AIC	Artifact types, required fields, layout regions, render targets
Expression	This document (Neon Ink)	Typography, panel grammar, page composition, brand voice

12.2 Required For Compiled SVG Artifacts

Compiled SVG artifacts should include:

<metadata id="sesm"><![CDATA[
{
  "sesm_version": "0.3.0"
}
]]></metadata>

Generated SVGs should include these top-level SESM fields when available: asset, artifact, theme, ui, crawl, llm, links, provenance, integrity.

Only sesm_version is required by SESM, but Aptlantis Studio production artifacts should include enough metadata to remain self-describing.

12.3 Neon Ink SESM Theme Block

Recommended theme block:

{
  "theme": {
    "id": "neon-ink",
    "name": "Neon Ink",
    "version": "0.1.0",
    "mode": "dark",
    "accent": {
      "name": "orange",
      "hex": "#F97316",
      "semantic_role": "code-heat",
      "semantic_family": "creation-build-code",
      "psychological_intent": "signal-hands-on-code-build-work"
    },
    "state": {
      "name": "active",
      "intensity": 2,
      "glow": "soft"
    },
    "priority": "medium",
    "tokens": {
      "void": "#050816",
      "base": "#0B0F1A",
      "panel": "#111827",
      "text": "#E5E7EB",
      "muted": "#94A3B8",
      "info": "#22D3EE",
      "structure": "#06B6D4",
      "process": "#A78BFA",
      "discovery": "#F472B6",
      "success": "#34D399",
      "important": "#FACC15",
      "critical": "#F43F5E",
      "code_heat": "#F97316"
    }
  }
}

12.4 Recommended Semantic Role Names

info, structure, navigation, reference, orientation, process, pipeline, transform, automation, discovery, featured, creative, success, verified, reproducible, important, caution, error, critical, blocked, constraint, code-heat, build, operation, experimental, research, prototype, canonical, archive, muted.

12.5 Recommended State Names

idle, active, running, featured, complete, verified, warning, error, archived, experimental, deprecated.

12.6 Provenance Expectations

Generated artifacts should record: generator name, generator version when available, build ID, source record IDs, template ID, source path or manifest reference, output path, reproducibility flag.

12.7 UI Hints

Generated SVGs should include useful UI hints when applicable: component type, preferred layout, preferred regions, responsive behavior, dimensions or aspect ratio, canonical interaction target.

Example:

{
  "ui": {
    "component_type": "dataset-hero-panel",
    "preferred_layout": "artifact-panel",
    "preferred_regions": ["dataset-header"],
    "responsive_behavior": "preserve-aspect-ratio",
    "dimensions": "intrinsic-svg-viewbox"
  }
}

13. Content & Voice Rules

13.1 Preferred Language

Use phrases like: high-signal datasets, small specialist models, local-first training, reproducible pipelines, compiled artifacts, curated niche corpora, dataset recipes, manifests, archive-ready releases, local machines, practical licensing.

13.2 Avoid

Avoid: AI magic, one-click intelligence, massive scraped everything, corporate productivity platform, generic chatbot branding, cloud-only framing, promises beyond dataset scope, vague claims of intelligence without data or evaluation context.

13.3 Copy Style

Copy should be concise, concrete, technically honest, builder-friendly, clear about constraints, and careful with licensing and quality claims.

13.4 Example Brand Copy

Build small. Train local. Create worlds.

Aptlantis Studio publishes focused datasets for builders who want useful
small models on personal hardware. Every release favors clear manifests,
durable formats, practical licensing, and reproducible pipelines over noisy
scale.

14. Brand Collateral Rules

14.1 Wordmark Usage

Use the full Aptlantis Studio wordmark on primary brand surfaces.

Do: keep generous negative space; use cyan, white, or violet on dark backgrounds; pair the wordmark with concise technical subtitles; preserve the Studio identity in the first viewport or first visual frame.

Avoid: generic AI platform mimicry; overused blue SaaS gradient identity; hiding dataset status or provenance; flattening all surfaces into plain static cards.

See the logo gallery for the current wordmark and icon assets.

14.2 Canva Assets

Canva templates should include primary colors (cyan, violet, magenta, void, panel, text), secondary colors (green, orange, yellow, red, muted slate), monospace labels, strong display headlines, reusable artifact panels, a dataset card template, a pipeline panel template, and a theme board template.

Canva assets do not need SESM metadata, but they should preserve Neon Ink's color meanings and artifact language.

14.3 Presentations

Presentation decks should use dark-first title slides, large display phrases, mono section labels, artifact panels for examples, semantic color tables, and screenshots or generated visuals where useful.

Slides should feel like guided archive views, not generic pitch templates. See References for the source .pptx/.pdf decks.

Social graphics may be punchier than website pages, but they should still use Neon Ink tokens, show dataset or artifact identity, keep claims concise, avoid generic AI hype, and preserve brand phrases and local-first positioning.

15. Validation Checklist

Use this checklist before treating a page, SVG, template, or brand asset as Neon Ink compliant.

15.1 Color

Uses NIPC v0.1 tokens for new work.
Uses legacy aliases only for existing mockups or generated SVG preservation.
Records semantic_role, semantic_family, psychological_intent, and intensity when generating semantic artifacts.
Uses one dominant accent per artifact.
Uses red/risk roles only for blockers, failures, hard constraints, or deprecation.
Uses green/trust roles only when evidence exists, such as validation, availability, reproducibility, or quality pass.
Uses yellow/attention roles as markers, not dominant surfaces.
Uses orange/code roles for Rust, build, execution, and artifact output, not arbitrary decoration.

15.2 Layout

Page reads as a navigable archive, not a generic SaaS dashboard.
Important artifact identity appears early.
Metadata remains visible where trust matters.
Panels have clear roles and states.
Glow is used for state/activity, not everywhere.

15.3 Components

Panel, border, glow, badge, metadata, and action each have a clear role.
Tags are semantically colored.
Badges are short and uppercase.
Dataset and pipeline cards expose enough scan-level metadata.

15.4 SESM

Compiled SVGs include SESM v0.2.0 metadata.
theme.id is neon-ink.
Theme metadata is NIPC-compatible when palette semantics matter.
Semantic role and family names match NIPC.
State names match this spec.
Generated artifacts include provenance when available.
SVGs point to canonical HTML, manifests, or related resources when useful.

15.5 Brand

Voice is precise, inventive, durable, and welcoming.
Copy favors high-signal data, local-first training, and reproducible pipelines.
Marketing surfaces use the same color meanings as the website.
No generic AI magic or cloud-only positioning.

16. Compatibility Notes

16.1 Relationship To Existing Screenshots

Current built page screenshots are important references for layout density, sidebar behavior, dataset-page structure, and artifact-panel composition. See the screenshot gallery.

They are not automatically canonical where they conflict with stronger system rules in this document.

16.2 Relationship To Existing Mockups

Mockups are reference material for visual direction, composition, and theme energy. See the mockup gallery.

They may include legacy color values or variant styling. New final pages should translate those ideas into NIPC v0.1 tokens.

16.3 Relationship To SESM v0.2

SESM v0.2 defines how semantic metadata is embedded in SVG assets. Neon Ink v0.1 defines the Aptlantis Studio design language and theme semantics that can be expressed inside SESM. See SESM Relationship.

16.4 Relationship To Theme Variants

Theme variants may adjust subject-specific emphasis while inheriting Neon Ink.

Example: Dungeon Synth may emphasize violet, green, and warmer fantasy imagery. Rust Code Corpus may emphasize orange, cyan, and technical metadata.

Variants must not invert core semantic meanings unless documented as a separate named standard.

16.5 Future Versions

Future Neon Ink versions may add: stricter accessibility contrast rules, formal component schemas, named theme variant specs, generator validation tests, design token package output, screenshot acceptance baselines, Canva template inventories.

Breaking changes should increment the major version. Additive changes should increment the minor version.

16.6 App Development Addendum

Neon Ink now explicitly covers desktop and application development. App adopters should treat the palette as a semantic operating system:

Primary neon identifies the dominant task or state.
Dim neon creates readable surfaces behind compact controls, rows, badges, and tool panels.
Glow neon is reserved for state amplification: active work, verified integrity, caution, critical risk, or keyboard/focus attention.
Flat neon is preferred for ordinary metadata, inactive controls, and dense catalog rows.

For data-dense applications:

lists should use icon, accent, and text together rather than color alone;
cards should represent individual artifacts or repeated items, not every page section;
health, verification, and repair surfaces should expose risk level, mutation behavior, and operator action clearly;
preview surfaces may be more expressive, but should still preserve the artifact's type and state;
desktop themes should define border, dim, and glow variants for every critical semantic family.

This addendum aligns Neon Ink with SFDS by clarifying implementation guidance that can be validated by real adopter projects such as FileCabinet (see the FileCabinet standard, which already implements the Neon Ink dark theme).

17. Summary

Neon Ink is the Aptlantis Studio standard for turning data into durable visual artifacts.

It unifies:

dark archival backgrounds
semantic neon color
panel-based composition
visible provenance
SESM-compatible SVG artifacts
local-first dataset publishing
precise builder-friendly brand voice

The north star is simple:

Aptlantis Studio should feel like an archive that is alive: static enough to last, structured enough to regenerate, and expressive enough to make datasets feel like artifacts worth exploring.

1. Overview​

2. Source Map​

3. Status & Scope​

3.1 Status​

3.2 In Scope​

3.3 Out of Scope​

4. Design Philosophy​

4.1 Signal Over Scale​

4.2 Local-First Durability​

4.3 Panels As Artifacts​

4.4 Dataset-First Publishing​

4.5 Welcoming Technicality​

4.6 Desktop Application Adaptation​

5. Terminology​

Artifact​

Artifact Panel​

Semantic Role​

Glow​

Semantic Family​

Psychological Intent​

State​

Theme Variant​

SESM Block​

Brand Surface​

6. Brand Foundation​

6.1 Position​

6.2 Audience​

6.3 Personality​

6.4 Core Phrases​

7. Color & Token System​

7.1 Background Layers​

7.2 Text Tokens​

7.3 NIPC Authority​

7.4 Core Stable Tokens​

7.5 Dataset Accent Language​

7.6 Legacy Color Aliases​

7.7 NIPC-Compatible Theme Token JSON​

7.8 Tailwind Token Map​

8. Typography​

8.1 Display Typography​

8.2 System Mono​

8.3 Body Copy​

8.4 Hierarchy​

9. Layout & Page Composition​

9.1 General Page Rules​

9.2 Home Page​

9.3 Dataset Detail Page​

9.4 About & Documentation Pages​

9.5 Pipeline Pages​

9.6 Theme Boards​

9.7 Marketing Surfaces​

10. Component Grammar​

10.1 Panel State Table​

10.2 Artifact Panel Requirements​

10.3 Badges​

10.4 Tags​

10.5 Q&A Accordion Pattern​

10.6 Links and Actions​

11. Dataset, Pipeline, and Artifact Patterns​

11.1 Dataset Card Metadata​

11.2 Pipeline Run Card​

11.3 Stats Tiles​

11.4 Related Dataset Lists​

11.5 SVG Artifact Panels​

12. SVG + SESM Requirements​

12.1 Relationship To SESM​

12.2 Required For Compiled SVG Artifacts​

12.3 Neon Ink SESM Theme Block​

12.4 Recommended Semantic Role Names​

12.5 Recommended State Names​

12.6 Provenance Expectations​

12.7 UI Hints​

13. Content & Voice Rules​

13.1 Preferred Language​

13.2 Avoid​

13.3 Copy Style​

13.4 Example Brand Copy​

14. Brand Collateral Rules​

14.1 Wordmark Usage​

14.2 Canva Assets​

1. Overview

2. Source Map

3. Status & Scope

3.1 Status

3.2 In Scope

3.3 Out of Scope

4. Design Philosophy

4.1 Signal Over Scale

4.2 Local-First Durability

4.3 Panels As Artifacts

4.4 Dataset-First Publishing

4.5 Welcoming Technicality

4.6 Desktop Application Adaptation

5. Terminology

Artifact

Artifact Panel

Semantic Role

Glow

Semantic Family

Psychological Intent

State

Theme Variant

SESM Block

Brand Surface

6. Brand Foundation

6.1 Position

6.2 Audience

6.3 Personality

6.4 Core Phrases

7. Color & Token System

7.1 Background Layers

7.2 Text Tokens

7.3 NIPC Authority

7.4 Core Stable Tokens

7.5 Dataset Accent Language

7.6 Legacy Color Aliases

7.7 NIPC-Compatible Theme Token JSON

7.8 Tailwind Token Map

8. Typography

8.1 Display Typography

8.2 System Mono

8.3 Body Copy

8.4 Hierarchy

9. Layout & Page Composition

9.1 General Page Rules

9.2 Home Page

9.3 Dataset Detail Page

9.4 About & Documentation Pages

9.5 Pipeline Pages

9.6 Theme Boards

9.7 Marketing Surfaces

10. Component Grammar

10.1 Panel State Table

10.2 Artifact Panel Requirements

10.3 Badges

10.4 Tags

10.5 Q&A Accordion Pattern

10.6 Links and Actions

11. Dataset, Pipeline, and Artifact Patterns

11.1 Dataset Card Metadata

11.2 Pipeline Run Card

11.3 Stats Tiles

11.4 Related Dataset Lists

11.5 SVG Artifact Panels

12. SVG + SESM Requirements

12.1 Relationship To SESM

12.2 Required For Compiled SVG Artifacts

12.3 Neon Ink SESM Theme Block

12.4 Recommended Semantic Role Names

12.5 Recommended State Names

12.6 Provenance Expectations

12.7 UI Hints

13. Content & Voice Rules

13.1 Preferred Language

13.2 Avoid

13.3 Copy Style

13.4 Example Brand Copy

14. Brand Collateral Rules

14.1 Wordmark Usage

14.2 Canva Assets
